ISUZU 10 Ton Reefer Truck for Meat Wholesalers
-
When You'll Get It:Jan 13 - Jan 17
-
Shipping & Support: In-stock items ship in 24 hours; custom orders ship per contract.
ISUZU 10 Ton Reefer Truck for Meat Wholesalers
Engineered for bulk meat wholesalers, industrial abattoirs, and regional cold chain logistics networks, the ISUZU 10 Ton Reefer Truck delivers immense cargo capacity and deep-freeze precision over long intercity hauls. Built on the heavy-medium ISUZU FVR commercial chassis (16,000–18,000 kg GVW), this truck is powered by a high-torque 6-cylinder ISUZU 6HK1 diesel engine (240 HP). The 10,000 kg payload capacity is housed within a massive 28–32 CBM thermally insulated body built with 100 mm high-density polyurethane insulation, maintaining critical core temperatures down to -25°C under extreme ambient heat.
Technical Specifications
- Kerb Weight (Kg)
- 4000
- Overall Dimensions(mm)
- 7445*2520*3595
- Box Volume(m³)
- 27
- Box Size（mm）
- 5100*2300*2300
- Refrigeration Temperature Range（℃）
- -5~-18
- Material of the Insulation Layer of the Box
- Polyurethane Foam
- Insulation Thickness（mm）
- 80
- Trade Name
- ISUZU
- Type of Fuel
- Diesel
- Front Axle/Rear Axle（t）
- 3/5.5
- Engine Power（kw）
- 87
- Gearbox
- 5-Speed Transmission
- Number of Axles
- 2
- Wheelbase (mm)
- 4200
- Tire Size
- 7.50R16
Standard Components Details
Common Optional Components
Factory Display
To meet stringent food hygiene and meat transport standards, the interior cargo box features seamless antibacterial FRP wall liners, reinforced roof subframes capable of mounting 4–6 lines of heavy-duty stainless steel meat hanging hooks, and an anti-slip 304 stainless steel or aluminum floor. An independent diesel refrigeration unit (Carrier Supra or Thermo King T-Series) ensures continuous temperature preservation even during extended truck staging or engine shutdown. We provide turnkey customization including multi-point digital temperature telemetry, side loading access doors, under-chassis standby plug-in units (380V), and 1.5-ton cantilever hydraulic tailgates. Consult our engineering team to customize your bulk meat distribution fleet.
Packing and Delivery
*Packing--Waxed or nude, and covered with tarpaulin.
*shlpping--small type can be shipped in 20"GP40"GPor 40"H0, big type can be shipped in bulk ship or RoROshipping,or according to your requirement.
